HDC36-18-1E - HD30 Series - Dust Cap for 18 Shell Receptacle - No Chain

Sku: HDC36-18-1E
Vendor: Deutsch
$23.93
Maximum quantity available reached.
Deutsch AEC

Deutsch HD30 Dust Caps

Deutsch metal HD30 Series provides quick and easy coupling and cost effectiveness with heavy duty terminations for the truck, bus and off-highway industries. The HD30 is a heavy duty rated, environmentally sealed, and multi-pin connector that uses a bayonet coupling system to provide a vibration resistant locking mechanism. These rugged connectors with seals fabricated from tear resistant, high temperature silicone, and a rear grommet, protect the contacts from moisture, sand, dust, lubricating oils, fuel, road salt, hydraulic fluid, grease, mud and other contaminants encountered in heavy duty operations.

Precision machined HD30 Series dust caps offer an easy and economical solution to protect plugs and receptacles from physical damage and harsh environmental conditions. The caps attach securely to protect the contact surfaces when disconnected from the appropriate connector.

 Part Number HDC36-18-1E
Series HD30 Series
Keyed No
Color Silver
material Aluminum
Shape circular
Connector Style Receptacle
Shell Size 18 shell
Modification No chain
Accessory y
Accessory Type Dust Cap
