0462-005-2031 - Solid Socket - Size 20 - 16-18 AWG, 7.5 Amps, Brown Stripe, Gold Plated

DEUTSCH - SOLID SOCKETS
The solid contacts are designed for use with larger wire size and heavy duty applications. Solid contacts are manufactured using a cold heading process with solid copper alloy wire and are available with either a nickel or gold plating finish. These contacts terminate wire from 6 AWG to 20 AWG (13 - 0.5mm2) and are available in 5 sizes each of the pin and socket. DEUTSCH industrial environmentally sealed electrical connectors are for critical applications and are designed to withstand the harshest and most challenging environments.
Part Number | 0462-005-2031 |
Series | HD30 Series, HDP20 Series, DRC Series, DTM Series, DRB Series, STRIKE Series |
Solid/Stamped and Formed | Solid |
Wire Size | 16, 18 |
Keyed | no |
Material | Gold |
Contact Size | 20 |
Current Rating | 7.5 |
Holds Pin/Socket | Socket |
